Zareba ESP10M-Z 10-Mile Solar Low Impedance Fence Charger

The Zareba 10 Mile Solar Fence Charger is used to control livestock and small animals; such as pets and nuisance animals.

The Zareba 10 Mile Solar Fence Charger powers up to 10 miles of fence and can be used with the following fence types: steel/aluminum, poly wire/poly rope and poly tape. Made in the USA, the solar panel features compartmental damage-resistant construction.

Low impedance technology allows for less battery drain and intuitive technology resists shorts when the fence is in contact with weeds.

Comes with a 1-yr limited warranty that includes damage caused by lightning.

At A Glance: Powers up to 10 miles of fence using a sun charged battery Input Voltage: 6 VDC Output Voltage: 7.5 KV +/- 20% open circuit voltage Can be used with steel, aluminum, poly wire, poly rope, and poly tape Low-impedance technology allows for less battery drain Resists shorts when the fence is in contact with weeds Includes a 1-year limited warranty including damage caused by lightning Made in the USA

Animals Controlled:

Fence Charger Expert Tips: The fence charger is the heart of your electric fence system. Consider the following factors to ensure you buy the right fence charger to meet your needs: Power source for your fence charger Type of fence line Area of fence and number of wire strands Weed conditions Type of animal controlled

Zareba 2 Mile Solar Charger Model: ESP2M-Z Powers up to 2 miles of fence Input Voltage: 4 VDC Output Voltage: 8 KV 1-year limited warranty

Zareba 3 Mile Solar Charger Model: SP3 Powers up to 3 miles of fence Input Voltage: 6 VDC Output Voltage: 7.2 KV 1-year limited warranty

Zareba 5 Mile Solar Charger Model: ESP5M-Z Rotates 360° on T-Post Powers up to 5 miles of fence Input Voltage: 6 VDC Output Voltage: 8.6 KV 1-year limited warranty

Zareba 10 Mile Solar Charger Model: ESP10M-Z Powers up to 10 miles of fence Input Voltage: 6 VDC Output Voltage: 7.5 KV 1-year limited warranty

Zareba 30 Mile Solar Charger Model: ESP30M-Z Powers up to 30 miles of fence Input Voltage: 12 VDC Output Voltage: 7.8 KV 2-year limited warranty

Voltage Minimum Requirements
Animal	Minimum recommended voltage on fence line*	Fence Recommendations	Animal	Minimum recommended voltage on fence line*	Fence Recommendations
Deer/Exotics	4000 - 5000+ volts	6 + tall to keep out deer, high visibility, minimum 7 strands	Horses	2000 - 3000 volts	White 2" poly tape or high tensile wire recommended, 3-5 strands
Sheep/Goats	4000 - 5000+ volts	Difficult to confine, 4-6 strands	Pigs	2000+ volts	To deter from rooting, use 3-4 wires starting 6" from ground
Predators	4000 - 5000+ volts	Wires spaced 6-8" apart, high output shock value	Nuisance pests	1000 - 2000 volts	Smaller animals require closer wire spacing
Bulls/Bison	3000 - 4000+ volts	Extra shock needed to control a determined bull, 4 strands minimum	Pets	700 - 1000 volts	3-4 wires, starting 6" from ground
Cows	2000 - 3000 volts	If docile with plenty of pasture, 1-3 strands	Poultry	500 - 900 volts	Anti-Roost device on commercial poultry feeding systems
*Zareba Systems voltage testers can help you determine if you have adequate voltage on your fence line.

Testing Your Fence

To ensure your fence is operating properly, and your animals are contained safely, it is important to test your fence regularly. Using a Zareba Systems Electric Fence Tester you can measure fence line and fence charger voltage.

Lightning And Power Surge Protection

Lightning is often the cause of fence charger failure. To prolong the life of your charger consider the following:

• Disconnect the charger from the power source when storms are near
• Install a lightning diverter/arrestor to divert lightning to the earth
• Use a lightning choke to dissipate power surges caused by lightning
